Aluminum Gate Kit Alu40 Universal DIY 6' x 6' BLACK
Aluminum Gate Kit Alu40 Universal DIY 6' x 6' BLACK
Regular price
$1,394.00 USD
Regular price
Sale price
$1,394.00 USD
Unit price
per
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
Care Instructions
Care Instructions
Description
The ALU40 Universal DIY Aluminum Gate Kit 6′ × 6′ combines a complete aluminum gate frame, sixteen 4-inch ALU40 horizontal slats and heavy-duty support hardware in a wall-to-wall pedestrian-gate package. It is made from USA-made 6063-T6 aluminum and finished with an AAMA 2604 architectural powder coating for a modern, low-maintenance exterior system. Explore the Universal DIY frame, ALU40 slat system, black exterior finish and support hardware from multiple views. Open any image for a larger look without leaving the product page. The Universal DIY platform organizes the gate around pre-engineered aluminum frame components, ALU40 horizontal slats and dedicated support hardware. The goal is a cleaner path from a verified wall-to-wall opening to an aligned finished pedestrian gate. This listing is a black 6′ × 6′ pedestrian single-swing gate with sixteen 4-inch ALU40 horizontal slats and a complete Universal DIY aluminum frame. The standard configuration is wall-to-wall only. The product listing combines the frame, gate stops, hinge support and sixteen black ALU40 slats into one pedestrian-gate package. The Universal DIY frame creates the single-swing gate structure without requiring welded field fabrication. The wider side frame is designed to accommodate most U.S.-size lock hardware so the latch and handle can be planned into the gate. Factory-prepared top and bottom frame components complete the Universal DIY gate perimeter. A coordinated T-stopper is included for the finished closing condition. The receiver-side component supports clean wall-to-wall closure and lock-side planning. One heavy-duty 5-inch support hinge is included. For true self-closing operation, a compatible hydraulic spring is recommended and sold separately. Sixteen 4″ × 6′ powder-coated 6063-T6 aluminum slats create the horizontal infill. Concrete footing, lock hardware, hydraulic self-closing spring and installation tools are not included with the standard kit. Post and cap options are selected separately when the project requires them. Concrete-footing conditions require the correct HD post configuration. At six feet wide and six feet high, this configuration creates a substantial pedestrian entry for front yards, side yards, courtyards and suitable light-commercial access points. The horizontal 4-inch ALU40 slats give the gate a broader architectural rhythm than narrower-slat systems, while the full aluminum frame keeps the design visually contained. Open any image to inspect additional product views in the built-in lightbox without leaving the product page. Use these drawings to understand the ALU40 profile and the gate-kit component relationship. Final opening conditions, mounting surfaces and hardware placement must still be verified for the actual installation. The Universal DIY package combines the gate frame, receiver-side components, ALU40 slat material and heavy-duty hinge support. Optional post and cap selections remain separate so the project can be matched to the actual mounting condition. Complete aluminum frame with wide lock side, top and bottom frame components for the 6′ × 6′ single-swing gate. Gate T-stopper and receiver L-stopper components support the finished closing condition and lock-side alignment. Sixteen 4″ × 6′ black powder-coated 6063-T6 aluminum slats are listed with this kit. One heavy-duty support hinge is included. A hydraulic closer or spring is a separate selection when true self-closing operation is required. The standard gate is wall-to-wall. Projects that require concrete footing must use the correct HD post upgrade instead of assuming posts are included. Additional posts and matching caps can be selected separately from the product-page options when the project condition requires them. The 6′ × 6′ format is suited to residential and light-commercial pedestrian applications when the opening and wall-to-wall support conditions match the Universal DIY system. Create a substantial modern entrance with six-foot height and broad horizontal aluminum lines. Use the six-foot-wide pedestrian leaf where the property needs more passage width than a narrow walkway gate. Coordinate the black gate with contemporary walls, fence systems and exterior architecture. The 4-inch horizontal ALU40 layout creates a strong architectural rhythm for private residential spaces. A practical aluminum option for pedestrian-only openings with suitable structural mounting conditions. Aluminum does not develop iron-oxide rust like steel and is well suited to environments where corrosion maintenance is a concern. The frame and ALU40 slats use 6063-T6 aluminum with an AAMA 2604 architectural powder-coated finish. The aluminum substrate does not rust like iron-based metal and will not rot, swell or splinter like wood. This standard SKU is designed for wall-to-wall mounting. Start with the opening and structural mounting surfaces, then assemble and align the gate around the actual site condition. Measure the opening at the top, middle and bottom and confirm the wall-to-wall mounting surfaces are plumb, solid and suitable for the gate hardware. Place the frame components on a protected flat surface, confirm orientation and keep the assembly square as the frame comes together. Install the sixteen 4-inch horizontal slats consistently according to the supplied system instructions and ordered gate configuration. Position the 5-inch HD support hinge for the required swing direction and verify the hinge-side structure can support the assembled leaf. Align the receiver-side components, T-stopper, L-stopper and selected lock hardware for clean closure. Check clearances, fasteners, latch engagement and smooth swing through the full arc before regular use. The Universal DIY system reduces fabrication work, but a six-foot-wide pedestrian leaf still depends on accurate site conditions and correct hardware planning. Confirm the finished opening at multiple heights and account for hinge, latch and receiver-side clearances. This SKU is supplied as a 6′ × 6′ gate. Do not assume the frame should be cut to an arbitrary size without confirming the correct configuration with Aluglobus. Plan the hinge side and swing direction around clearance, traffic flow and the actual opening. Confirm the selected latch or lock body and required clearances before finalizing the lock-side setup. If true self-closing operation is required, select the appropriate hydraulic spring or compatible closing hardware separately. The standard configuration is wall-to-wall. Concrete-footing projects require the correct HD post upgrade before installation. Watch the Universal DIY gate system and ALU40 gate footage for a closer look at the aluminum profiles, assembly approach and finished design language. Both videos load only after the visitor clicks the poster. Common questions about the package, aluminum construction, wall-to-wall installation, finish, hardware and ALU40 system. If the opening is already confirmed as a compatible wall-to-wall 6′ × 6′ condition, proceed with the listed gate. If not, send the opening dimensions and photos before ordering. Before assembly, make sure the opening and support conditions match the Universal DIY system. For nonstandard openings, concrete-footing conditions or uncertainty about the hinge and receiver sides, send the project information before ordering. For a verified standard wall-to-wall condition, purchase the listed kit directly.A black 6′ × 6′ single-swing aluminum gate built around the Universal DIY frame.
Gate size6′ wide × 6′ high
OperationPedestrian single swing
ALU40 slats16 × 4″ × 6′
Standard colorBlack
See the frame, ALU40 slat system, finish and hardware from multiple angles.
Full-frame strengthUniversal DIY frame
Universal ALU40 compatibilityALU40 horizontal system
Long-lasting powder coatExterior black finish
Reinforced hinge supportSingle-swing hardware
Premium aluminum construction6063-T6 system
DIY-oriented assemblyPre-engineered system
A factory-prepared aluminum gate system without welded field fabrication.
The ALU40 Black 6′ × 6′ Universal DIY gate at a glance.
A coordinated 6′ × 6′ gate package built around the Universal DIY frame.
Complete aluminum gate frame
Wide lock-side frame
Top and bottom frame
Gate T-stopper
Receiver L-stopper side component
5″ HD support hinge · Qty 1
16 black ALU40 slats
What is not included
Optional posts and caps
Why this 6′ × 6′ configuration
Six feet of width and height with a clean horizontal ALU40 rhythm.
Additional views of the ALU40 6′ × 6′ gate system.
ALU40 6′ × 6′ gate view 01Product view
ALU40 6′ × 6′ gate view 02Product view
ALU40 6′ × 6′ gate view 03Product view
ALU40 6′ × 6′ gate view 04Product view
ALU40 6′ × 6′ gate view 05Product view
ALU40 6′ × 6′ gate view 06Product view
ALU40 profile geometry and the 6′ × 6′ Universal DIY gate layout.
ALU40 profile2D and 3D technical view
6′ × 6′ gate layout3D view and parts legend
Hinge referenceHeavy-duty support hardware
Understand the frame, receiver hardware, ALU40 slats and support components before assembly.
Universal gate frame
Receiver and striker side
ALU40 slat package
5″ HD support hinge
Optional HD post upgrade
Optional posts and caps
Built for pedestrian openings where a modern aluminum gate and low routine maintenance matter.
Front pedestrian entries
Side-yard gates
Courtyards and entryways
Privacy-oriented entries
Light-commercial pedestrian access
Coastal and humid climates
6063-T6 aluminum, architectural powder coating and no iron-oxide rust.
A six-step path from verified opening to aligned single-swing gate.
Verify the opening
Lay out the Universal frame
Install the 16 ALU40 slats
Set hinge hardware
Set the receiver side
Align and test
Confirm the opening, swing, lock hardware and support condition before assembly.
Measure wall to wall
Confirm the listed size
Confirm swing direction
Plan lock hardware
Check self-closing needs
Confirm mounting condition
See the Universal DIY gate system in motion.
Answers before you assemble the 6′ × 6′ gate.
What is included in the ALU40 Universal DIY 6′ × 6′ kit?
The listing includes the complete aluminum gate frame, wide lock-side frame, top and bottom frame, gate T-stopper, receiver L-stopper side component, one heavy-duty 5-inch support hinge and sixteen black 4-inch by 6-foot ALU40 horizontal slats.Is the aluminum gate rust-resistant?
Yes. The 6063-T6 aluminum does not develop iron-oxide rust like steel. The AAMA 2604 architectural powder coating adds exterior surface protection. Routine cleaning is still recommended, especially in coastal environments.Can I install the gate myself?
The system is designed for DIY assembly and is listed at an intermediate DIY skill level. Accurate measurement, frame squaring, drilling, fastening and hinge alignment are still important.Can I modify this 6′ × 6′ kit to any other size?
This SKU is supplied as a 6′ × 6′ gate. The Universal platform is used across multiple ALU40 gate sizes, but do not assume this specific kit should be cut or changed to an arbitrary dimension. Confirm the correct size or custom configuration with Aluglobus before altering components.How long will the powder-coated finish last?
The gate uses an AAMA 2604 architectural powder-coated finish intended for exterior exposure. Actual appearance over time depends on climate, cleaning, physical wear and site conditions.Does the wide side frame accept common lock hardware?
The product listing states that the wide side frame fits most U.S.-size lock hardware. The lock itself is not included, so confirm the selected lock body and installation requirements before assembly.Can the standard gate be installed with posts set in concrete?
Not in the standard configuration. This Universal DIY gate is listed for wall-to-wall installation only. A concrete-footing condition requires the appropriate HD post upgrade and should be specified before installation.Can the gate be self-closing?
The heavy-duty support hinge is listed as self-closing capable, but the product page recommends a hydraulic spring for true self-closing operation. That spring is sold separately.Are installation tools included?
No. Installation tools are not included. The exact anchors, drill bits and fastening hardware required can vary with the wall or structural mounting surface.Buy the listed 6′ × 6′ kit, or verify the opening first.
Do not guess on a 6-foot-wide single leaf.
Confirm the fit first, or order the listed 6′ × 6′ kit.
